Calibration procedure
To correctly calibrate the hopper discriminator, put 25 coins of € 1 euro (Ø 23 mm and thickness
2.2 mm) or of similar physical measurements into the hopper. Then follow the steps listed in
paragraph 4:
“ALGORITHM AND SEQUENCE OF COMMANDS TO PERFORM THE CALIBRATION” in the
manual "Protocol cctalk Discriminator".
If you want to implement this provision in the machine, can follow the recommendations in
section 4.2:
“DEVELOPMENT SOFTWARE TO CARRY OUT THE CALIBRATION PROCESS”.
The recalibration may be done by the machine, if you have implemented this provision in your
software or with the ccTalk Manager Tool of Azkoyen, follow the steps listed in the chapter:
“Execution of processes  Discriminator  Calibrate”, page 24.
.
