5.2.6 Advanced
Configuration
Token properties
• Write protection (ON/OFF)
• Power on load (ON/OFF)
• On time load (ON/OFF)
Parameter Selection
• Group 0 (ALL)
• Group 1 (User)
• Group 2 (PRV)
• Group 3 (FACT)
• Group 4 (PORT A)
• Group 5 (PORT B)
•
Group 0 (SECURATY)
Store to
Token
Store the selected device datas at the memory token.
Restore from
Token
Restoring data from the memory token to the device.
Encoder protocol
• Disabled
• V1
• V2
Absolute Digital Encoder (ADE
®
). Remote meter reading technology
using ASCII communications protocols.
Totalizer Dial
4-dial up to 10-dial
Select the number of digits that the totalizer should display.
For example 6-dial will be displayed with 6 total digits like
12.3456 m³/h.
Note: A totalizer roll over can be indicated by a totalizer alarm via the
digital output (see Digital Output / Functional selection)
See also Totalizer Resolution.

Badger Meter ModMAG M2000 Specifications

General

Flow Measurement Technology	Electromagnetic
Enclosure Rating	NEMA 4X (IP66)
Repeatability	±0.1% of rate
Output	4-20 mA, pulse, frequency
Display	LCD with backlight
Power Supply	100 to 240 VAC or 24 VDC
Communication Protocols	HART, Modbus
Process Connection	Flanged, Threaded
Electrode Material	316 Stainless Steel, Hastelloy, Tantalum
Liner Material	PTFE, PFA, Polyurethane
Accuracy	±0.2% of rate
Temperature Range	-40°...160°F (-40°...71°C)
Fluid Temperature	-4°...302°F (-20°...150°C)
Materials	Stainless Steel, Carbon Steel
