OmniCare EVC System
Installation & Commissioning Manual
OmniCare issue 1
5
C
O
M
M
U
N
I
C
A
T
I
O
N
S
1.2.4 Fire Telephone Remote Unit (BVFHL)
Figure 1.4 — Typical Fire Telephone Remote
Fire Telephone Remote
Indicators System OK
Power supply 12 - 40V DC
Current consumption 30mA @ 30V typical
Dimensions (W x H x D) Surface Mount: 130mm x 350mm x 100mm
Bezel: 170mm x 390mm x 20mm
Bezel cut out: 138mm x 358mm
Knockouts 20mm and 25mm diameter in sides of back box
Weight 4 Kg
Temperature Range -10 to + 40°C (storage and operating)
Humidity Range 95% Non Condensing
