OmniCare EVC System
Installation & Commissioning Manual
20 OmniCare issue 1
C
O
M
M
U
N
I
C
A
T
I
O
N
S
3.2 INSTALLING THE REMOTE UNITS
3.2.1 Disabled Refuge Remotes (BVOCECP)
Figure 3.1 — Mounting Holes and Knockout Locations
1. If possible, before connecting the Remote Units check the
CA U T I O N
The OmniCare EVC System Remote Units can be damaged if
either of the following situations occur:
• If Power is connected across the Data pair,
• If Power is reversed i.e. 0V and +V swapped.
To prevent damage to the Remote Units ensure the
Commissioning Procedures in this manual are completed before
connecting the Control Panel(s) or applying power to the Circuit
Cabling.
