OmniCare EVC System
Installation & Commissioning Manual
OmniCare issue 1
87
C
O
M
M
U
N
I
C
A
T
I
O
N
S
A Addendum
A.1 MAXIMUM CABLE LENGTHS AND
R
ESISTANCE VALUES
The maximum length cable length between the Control Panel and
the First Remote Unit, or between each Remote Unit must not
exceed the following distances unless a Repeater Unit is used.
The following table states nominal resistance values for the
different types of cable normally encountered.
Table A.1 — Resistance Values for Different Cable Types
MICC (lightweight) 4-core Distance between units not to exceed 150m.
MICC (heavyweight) 4-core Distance between units not to exceed 200m.
FP200 4-core Distance between units not to exceed 200m.
FP Plus 4-core Distance between units not to exceed 200m.
Cable Type DCΩ per KM Max DCΩ per single link
FP200 1.0mm 18.1Ω 3.62Ω
FP200 1.5mm 12.1Ω 2.42Ω
FP200 2.5mm 7.4Ω 1.48Ω
MICC 1.0mm 17.2Ω (LW) 2.58Ω (HW) 3.44Ω
MICC 1.5mm 11.4Ω (LW) 1.71Ω (HW) 2.28Ω
MICC 2.5mm 6.8Ω (LW) 1.02Ω (HW) 1.36Ω
