3.3 INSTALLING THE CONTROL PANEL(S)
The OmniCare EVC System uses three different size Control
Panels depending on the number of Remote Units in use.
3.3.1 Minicare Control Panels (8, 16, and 32 zone)
Figure 3.15 — Mounting Hole Centres & Rear Knockout Positions
Figure 3.16 — Top Knockout Positions
NOTE: The weight of a Control Unit with batteries is 20KG.
Ensure the wall or mounting point is of sufficient strength to support the
weight of the unit.
