1. Fit the OmniCare EVC System Control Panel to the wall
using suitable fixings.
The panel is designed for either surface mounting (using the
4 off 9mm holes shown in
Figure 3.15), or it can be flush
mounted using an optional bezel.
2. Fit suitable glands and prepare the Circuit Cables for
termination (i.e. ensure sufficient length is available and label
each conductor) but do not connect the Circuit Cables to the
Control Panel at this time.
CA U T I O N
The OmniCare EVC System Remote Units can be damaged if
either of the following situations occur:
• If Power is connected across the Data pair,
• If Power is reversed i.e. 0V and +V swapped.
For these reasons it is recommended to leave the Circuit Cables
disconnected from the Control Panel(s) until the System is to be
Commissioned.
