4.4 COMMISSIONING PROCEDURE
4.4.1 Testing Loop Integrity (Power Cables)
It is recommended to test each ring of the system individually, so
initially ensure all circuits are disconnected from the Panel.
1. At the Master Panel, connect the end of the first loop circuit
to the “A” terminations (refer to
Figure 2.2 on page 14).
Ensure the unconnected cables at the other end of the loop
are suitably positioned to prevent short circuits.
2. Connect the Mains Power, but do not connect the batteries.
3. Press the “FAULT ACCEPT” button to accept the faults and
silence the buzzer.
4. Using a voltmeter, check the voltage across the “+V” and
“0V” terminals on the “A” circuit is approximately 30V DC.
Wait for 10 seconds and then check the return voltage on the
“+V” and “0V” cables (“B” circuit) is higher than 22V DC.
5. If the reading is higher than 22V DC then the loop integrity
of the power conductors is confirmed.
CA U T I O N
Before applying power to a loop ensure the "0V Continuity
Check" described in
Section 4.3 has been successfully completed.
Ensure Mains Power and batteries are disconnected before
connecting or disconnecting Loop Cables.
NOTE: If the "B" connections are also made during commissioning the
panel will automatically route data and power around the ring. This
makes diagnosis of any cable faults much more difficult.
NOTE: The actual return voltage depends on the number of Remote Units
and the cable length of the loop.
CA U T I O N
If the reading on the return cables is less than 22V DC then power
is not being fed along the loop.
Investigate the +V loop wiring before proceeding.
To Next Page
