OmniCare EVC System
Installation & Commissioning Manual
OmniCare issue 1
23
C
O
M
M
U
N
I
C
A
T
I
O
N
S
Table 3.2 — Tone Configuration Default Settings
6. Refit the retaining bracket over the blue termination block
and replace the screw.
7. Connect the green and yellow safety earth lead to the earth
terminal in the back box.
8. Fit the Remote Unit to the back box using four screws.
JP # Option
J2 Reset by either Keyswitch or Control Panel
J3 Audio Self Test disabled
J4 Auto PTT enabled
J5 Calls only allowed when Fire Panel is Active
J6 "Inactive" message enabled
SW 1 AssureCare emulation disabled
NOTE: Fitting a jumper overides the relevant Tone Configuration option.
