The specifications are typical values for
BTL PF _ 400- _ _ _ _ -C12NL _ _ -0-000S04 with 24VDC
and at room temperature and with a measuring length of
500 mm in conjunction with the magnet BTL5-P-3800-2,
BTL5-P-4500-1, BTL5-P-5500-2, BTL6-A-3800-2,
BTL6-A-3801-2, BTL5-F-28141-S or BTL5-T-28141-S.
The product is immediately ready for operation, full
accuracy is achieved after the warm-up phase.
Further data can be found at www.balluff.com
on the product page.
9.1 Ambient conditions
Ambient temperature −25…+85°C
Storage temperature −40…+100°C
Relative humidity ≤ 90%,
non-condensing
Typ. temperature coefficient
1)
≤ 30 ppm/K
Shock rating as per
EN 60068-2-27
2), 3)
100g/6ms
Continuous shock per
EN 60068-2-27
2), 3)
50 g/2ms
Vibration per EN 60068-2-6
2), 3)
12g, 10 …2000Hz
Protection per IEC60529 (when
threaded together)
IP67
9.2 Detection range/Measuring range
Measuring length 25...4000mm
Resolution 5μm
Repeat accuracy ≤±10µm
Length-dependent measuring
frequency
Measuring length ≤ 1270mm 1000Hz
Measuring length > 1270 to
≤2650mm
500Hz
Measuring length > 2650mm 250Hz
Non-linearity ≤±50µm
Detectable speed ≤ 10m/s
9.3 Electrical data
Operating voltageU
b
18…30VDC
Current draw (at24VDC) ≤ 60mA
Power consumption ≤ 1.5W
Overvoltage protection U
b
up to 36VDC
Voltage-proof up to (GND – Housing) 500VDC
9.4 Electrical connection
Short circuit protection Signal output to
GND and
30VDC
Polarity reversal protected U
b
up to 30VDC
9.5 Interface
IO-Link version 1.1
Transmission rate COM2 (38.4 kBaud),
COM3 (230.4 kBaud)
Cycle Time ≥1ms
Data format 32Bit signed
Error value 0x7FFFFFFC
9.6 Materials
Housing material Aluminum
Cover material Zinc die cast, galvanized
9.7 Mechanical features
Housing height 20.8mm
Weight (depends on length) Approx. 1 kg/m
1)
Measuring length 500mm, magnet in the middle of the measuring range
2)
Individual specifications as per Balluff standard
3)
Resonant frequencies excluded
9
Technical data
BTL PF _ 400- _ _ _ _ -C12NL _ _ -0-000S04
Magnetostrictive Linear Position Sensor – Profile Style

Balluff BTL PF 400 Series Specifications
