Defined Area Height
Standard 14 mm Resolution Models 0.1 m to 6 m (4 in to 20 ft) range
Emitter (8-pin) Receiver Emitter/Receiver Pair Number of Beams
Response Time
(Tr)
150 mm (5.9 in) SLSE14-150Q8 SLSR14-150Q8 SLSP14-150Q88 20 11 ms
300 mm (11.8 in) SLSE14-300Q8 SLSR14-300Q8 SLSP14-300Q88 40 15 ms
450 mm (17.7 in) SLSE14-450Q8 SLSR14-450Q8 SLSP14-450Q88 60 19 ms
600 mm (23.6 in) SLSE14-600Q8 SLSR14-600Q8 SLSP14-600Q88 80 23 ms
750 mm (29.5 in) SLSE14-750Q8 SLSR14-750Q8 SLSP14-750Q88 100 27 ms
900 mm (35.4 in) SLSE14-900Q8 SLSR14-900Q8 SLSP14-900Q88 120 32 ms
1050 mm (41.3 in) SLSE14-1050Q8 SLSR14-1050Q8 SLSP14-1050Q88 140 36 ms
1200 mm (47.2 in) SLSE14-1200Q8 SLSR14-1200Q8 SLSP14-1200Q88 160 40 ms
1350 mm (53.1 in) SLSE14-1350Q8 SLSR14-1350Q8 SLSP14-1350Q88 180 43 ms
1500 mm (59 in) SLSE14-1500Q8 SLSR14-1500Q8 SLSP14-1500Q88 200 48 ms
1650 mm (65 in) SLSE14-1650Q8 SLSR14-1650Q8 SLSP14-1650Q88 220 52 ms
1800 mm (70.9 in) SLSE14-1800Q8 SLSR14-1800Q8 SLSP14-1800Q88 240 56 ms
To order the 5-pin emitters with the Test input, replace the suffix “Q8” with “Q5”, (e.g., SLSE14-150Q5), and for the pair
replace “Q88” with “Q85” (e.g., SLSP14-150Q85).
To order the pigtail QD (8-pin only) model, replace the “Q” in the model number with “P” (e.g., SLSE14-150P8).
To order the ESD-safe models, add “N” to the model number, prior to the QD option designation (e.g., SLSE14-150NQ8).
ESD-safe models are not available with the pigtail QD option.
To order optional housing finishes, add these letters in front of the QD designation in the model number,
• add “A” for a clear (brushed) anodized aluminum finish, black endcaps (e.g., SLSE14-150AQ8),
• add “S” for a nickel-plated (“silver”) finish, black endcaps (e.g., SLSE14-150SQ8),
• add “B” for a black painted finish, black endcaps (e.g., SLSE14-150BQ8),
• add “W” for a white painted finish, black endcaps (e.g., SLSE14-150WQ8), or
• add “SO” for a “safety orange” painted finish, black endcaps (e.g., SLSE14-150SOQ8).
4.3 Standard Emitter and Receiver Models (Non-
Cascadeable) with 30 mm Resolution
The standard 8-pin QD models are listed; 8-pin emitters/receivers feature “swapable” wiring. Order one 8-pin cable for each
8-pin emitter or receiver, or one 5-pin cable for each 5-pin emitter.
For cascadeable 30 mm emitter and receiver models, see
Cascadeable Emitter and Receiver Models with 30 mm
Resolution
on page 63.
Defined
Area Height
Standard 30 mm Resolution Models 0.1 m to 18 m (4 in to 60 ft) range
Emitter (8-pin) Receiver Emitter/Receiver Pair Number of Beams Response Time (Tr)
150 mm (5.9 in) SLSE30-150Q8 SLSR30-150Q8 SLSP30-150Q88 10 9 ms
300 mm (11.8 in) SLSE30-300Q8 SLSR30-300Q8 SLSP30-300Q88 20 11 ms
450 mm (17.7 in) SLSE30-450Q8 SLSR30-450Q8 SLSP30-450Q88 30 13 ms
600 mm (23.6 in) SLSE30-600Q8 SLSR30-600Q8 SLSP30-600Q88 40 15 ms
750 mm (29.5 in) SLSE30-750Q8 SLSR30-750Q8 SLSP30-750Q88 50 17 ms
900 mm (35.4 in) SLSE30-900Q8 SLSR30-900Q8 SLSP30-900Q88 60 19 ms
1050 mm (41.3 in) SLSE30-1050Q8 SLSR30-1050Q8 SLSP30-1050Q88 70 21 ms
1200 mm (47.2 in) SLSE30-1200Q8 SLSR30-1200Q8 SLSP30-1200Q88 80 23 ms
1350 mm (53.1 in) SLSE30-1350Q8 SLSR30-1350Q8 SLSP30-1350Q88 90 25 ms
EZ-SCREEN
®
14/30 mm Safety Light Screen
www.bannerengineering.com - Tel: + 1 888 373 6767 13
