11.5 Center Bracket
Model EZA-MBK-12: The center bracket is supplied with emitters and receivers over 1050 mm (3.4 ft) and longer.
Dimensions are identical for stainless steel model EZA-MBK-12N for ESD model emitters and receivers.
20 mm
(0.79")
20 mm
(0.79")
Ø 60 mm
20 mm
(0.79")
17.5 mm
(0.69")
55 mm
(2.17")
50 mm
(1.97")
4.2 mm
(0.17")
55.6 mm
(2.19")
15 mm
(0.59")
20.0 mm
(0.79")
10 mm
(0.39")
9.5 mm
(0.37")
36 mm
(1.42")
Ø 8.3 mm
(0.33")
Ø 7 mm
(0.28")
11.6 Emitter and Receiver Mounting Dimensions and Location
of Defined Area
EZ-SCREEN
®
14/30 mm Safety Light Screen
