Banner EZ-SCREEN - Accessories; Interface Modules

12 Accessories
12.1 Interface Modules
IM-T-..A interface modules provide forced-guided, mechanically-linked relay (safety) outputs for the EZ-SCREEN System
See Banner datasheet p/n 62822 and wiring diagrams for more information.
Model Description
IM-T-9A Interface module, 3 normally open (N.O.) redundant-output 6 amp contacts
IM-T-11A Interface module, 2 normally open (N.O.) redundant-output 6 amp contacts, plus 1 normally closed (N.C.) auxiliary
contact
12.2 Contactors
The normally closed contacts are used in an external device monitoring (EDM) circuit. If used, two contactors per EZ-
SCREEN System are required.
Model Description
11-BG00-31-D-024 10 amp positive-guided contactor, 3 N.O., 1 N.C.
BF1801L024 18 amp positive-guided contactor, 3 N.O., 1 N.C. (N.C. contact rated at 10 amps)
12.3 Safety Controllers
Safety Controllers provide a fully configurable, software-based safety logic solution for monitoring safety and non-safety
devices. For additional models and XS26 expansion modules, see instruction manual p/n
174868 (XS/SC26-2).
Non-Expandable Models Expandable Models Description
SC26-2 XS26-2 26 convertible I/O and 2 Redundant Solid State Safety Outputs
SC26-2d XS26-2d 26 convertible I/O and 2 Redundant Solid State Safety Outputs with Display
SC26-2e XS26-2e 26 convertible I/O and 2 Redundant Solid State Safety Outputs with Ethernet
SC26-2de XS26-2de 26 convertible I/O and 2 Redundant Solid State Safety Outputs with Display and Ethernet
SC10-2roe 10 Inputs, 2 redundant relay safety outputs (3 contacts each)
12.4 Muting Modules
Model Mounting Description
MMD-TA-11B
DIN-mount Muting module
2 N.O. safety outputs (6 amps), 2 or 4 muting inputs, SSI, override input; IP20;
terminal connections
MMD-TA-12B 2 OSSD outputs, 2 or 4 muting inputs, SSI, override input; IP20; terminal connections
12.5 AC Boxes
AC power supply for use with EZ-SCREEN emitters and/or receivers. Models EZAC-R.. can be interfaced with up to three
receivers or two cascaded emitter/receiver pairs; models EZAC-E.. can power up to four emitters. Box supplies +24V dc
power at 0.7 amps (16.8 W max. power); accepts input voltages from 100 to 250V ac (50 to 60 Hz); IP65 metal housing.
EZ-SCREEN
®
14/30 mm Safety Light Screen
88 www.bannerengineering.com - Tel: + 1 888 373 6767
