10.3 Ethernet Cordsets
Cat5e Shielded Cordsets Cat5e Crossover Shielded Cordsets Length
STP07 STPX07 2.1 m (7 ft)
STP25 STPX25 7.62 m (25 ft)
STP50 STPX50 15.2 m (50 ft)
STP75 STPX75 22.9 m (75 ft)
10.4 Interface Modules
NOTE: External device monitoring (EDM) is required to be wired separately to the N.C. contacts to
comply with ISO 13849-1 categories and ANSI/OSHA control reliability; see EDM and FSD Hookup on
page 90.
IM-T-9 series interface modules have 6A output, 22.5 mm DIN-mount housing, removable (plug-in) terminal blocks, low
current rating of 1V ac/dc at 5 mA, high current rating of 250 V ac/dc at 6A. See datasheet p/n 62822 for more
information.
Model
Supply Voltage Inputs Safety Outputs Output Rating EDM Contacts Aux. Outputs
IM-T-9A
24V dc
2 (dual-channel
hookup)
3 N.O.
6 amps 2 N.C.
—
IM-T-11A 2 N.O. 1 N.C.
10.4.1 Mechanically Linked Contactors
Mechanically Linked Contactors provide an additional 10 or 18 amp carrying capability to any safety system. If used, two
contactors per Safety Output pair are required for Category 4. A single OSSD output with 2 contactors can achieve
Category 3. The N.C. contacts are to be used in an external device monitoring (EDM) circuit.
NOTE: EDM is required to be wired separately to the N.C. contacts to comply with ISO 13849-1
categories and ANSI/OSHA control reliability; see EDM and FSD Hookup on page 90 .
Model Supply Voltage Inputs Outputs Output Rating
11-BG00-31-D024
24 V dc 2 (dual-channel hookup) 3 N.O. and 1 N.C.
10 amps
11-BF18C01-024 18 amps
XS/SC26-2 Safety Controller
