5.1 Configuration Mode
Configuration Mode provides options to send the current configuration to an SC-XM2 drive and to receive a configuration
from the SC-XM2 drive.
NOTE: A password is required to access the Configuration Mode menu.
Important: Entering the Configuration Mode turns Off Safety Outputs.
To write data to an SC-XM2 drive:
1. Insert the SC-XM2 drive into the Safety Controller.
2. From the System Menu, select Configuration Mode.
3. Enter the password.
4. Hold OK until the Configuration Mode menu appears.
5. Select Writo to XM.
NOTE: Writing to XM process copies all data (Configuraton, Network Settings, and passwords to
the SC-XM drive.
6. Wait for the write process to complete.
7. Reset the System.
To import data from an SC-XM2 drive:
1. Insert the SC-XM2 drive into the Safety Controller.
2. From the System Menu, select Configuration Mode.
3. Enter the password.
4. Hold OK until Configuration Mode menu appears.
5. Select Import from XM:
• For configuration only, select Configuration
• For network settings only, select Network Settings
• For configuration and network settings, select Configuration/Network
• For all data, which includes configuration, network settings, and user passwords, select Config/Network/
Passwords
6. Wait for the import process to complete.
7. Reset the System.
XS/SC26-2 Safety Controller
65
