R5900087 /04 ClickShare CSE-200+ 27
2.2 CSE-200+ specifications
Base Unit
Dimensions (HxWxD) 39mm x 200mm x 202mm
Power supply Standard 110/220 V AC plug
Power consumption Operational: 50W (max)
Standby: <8W (networked standby), < 0.5W (deep standby mode)
Weight 900 gr
Operating system Windows 7/8/8.1/10 32 & 64 bit
macOS 10.13/10.14 (Mojave)
Android v7 & v8 & 8.1 (ClickShare app)
iOS 11, 12 (ClickShare app)
Video outputs 1x HDMI 1.4b
Video inputs 1x HDMI 1.4b
Output resolution 4K UHD (3840*2160) @ 30Hz
AirPlay Support iOS mirroring (AirPlay) from iOS 9.0 up to iOS 12 / Mac OS 10.14 (Mojave)
Google Cast Support Android 9
Miracast support Miracast R2 support Windows 10
Input resolutions 1920x1080 @60Hz
Noise Level Max. 25dBA @ 0-30°C
Max. 30dBA @ 30-40°C
Number of sources
simultaneous on screen
2
Number of simultaneous
connections
16
iPad, iPhone and Android
compatibility
Sharing of documents, browser, camera for both Android and iOS devices
via ClickShare app
Extended desktop Available (depending on your operating system). May require ClickShare
Extension Pack.
Authentication protocol WPA2-PSK in stand alone mode
WPA2-PSK or IEEE 802.1X using the ClickShare Button in network
integration mode
Wireless transmission
protocol
IEEE 802.11 a/b/g/n/ac and IEEE 802.15.1
Reach Adjustable with signal strength modulation; max. 30m (100 ft) between
ClickShare Button and ClickShare Base Unit
Frequency band 2.4 GHZ and 5 GHz (DFS channels supported in select number of
countries - coming soon)
Connections 1x Ethernet LAN 1Gbit
1x USB Type-C 2.0 (back); 2x USB Type A 2.0 (back); 1x USB Type A 2.0
(front)
Audio analog line out on mini jack socket (3.5mm), digital S/PDIF
