Barco ClickShare CSE-200+ Installation Manual

R5900087 /04 ClickShare CSE-200+ 63
4. To select the audio output, click on the drop down box and select the desired audio output.
Jack: audio output via jack.
HDMI: audio output via HDMI.
SPDIF: digital audio ouput via TOSLINK
5. Click on Save changes to apply the new settings.
6.11 WiFi settings
WARNING: It is not allowed to operate the Base Unit outside its intended geographical region.
Dual network mode
Simultaneous connection to two different networks for better company integration is possible. One via the
physical interface (LAN interface) and one over WiFi.
Dual network functionality allows for instance to connect simultaneously to the corporate and guest LAN,
allowing both employees and guests to share content via the ClickShare App, Airplay or Google Cast to the
ClickShare unit without changing their network connection. This eliminates the need for the IT administrator to
route traffic between the two networks. The built-in firewall in the Base Unit prevents any traffic bridging
between the two connected networks.
About WiFi
A connection with the Base Unit can be made via a wireless connection. A fixed wireless IP address is used to
establish the connection.
The transmission power of the wireless signal can be reduced.
An overview of the current settings is given when Wi-Fi Settings is selected and operational mode is Access
Point.
Image 6-18: WiFi settings
CSE-200+ Configurator

Barco ClickShare CSE-200+ Specifications

General

Wireless Frequency Band	2.4 GHz and 5 GHz
Video Outputs	HDMI
Number of Sources Simultaneously on Screen	2
Native Protocols	AirPlay, Google Cast, Miracast
Wireless Sharing	Yes
Resolution	Up to 4K UHD (3840x2160)
Security	WPA2
Compatibility	Windows, macOS, iOS, Android
Operating System	Windows, macOS, iOS, Android
Frame Rate	30 fps
Output Resolution	Up to 4K UHD (3840x2160)
Audio	HDMI audio
USB	USB-A
ClickShare Buttons	2
Authentication Protocol	WPA2
Wireless Transmission Protocol	IEEE 802.11ac
Reach	30 meters
Maximum Number of Presenters	8
Connection Type	Wireless
Resolution Support	Up to 4K UHD (3840x2160)
