R5900087 /04 ClickShare CSE-200+ 29
1 USB Type-A port
2 Status LED ring
3 Standby Button
USB Port
The USB port is used to pair the Button to the Base Unit and to update the software of both the Base Unit and
the Buttons.
When plugging in the Button into the Base Unit, the Button is paired to the Base Unit. The Base Unit checks
whether the software and firmware of the Button is up to date. If not, the Base Unit updates the software and/
or firmware.
Use a convertor to connect a Button with an USB Type-C
TM
connector to front USB port of the Base Unit. USB
Type-C
TM
port available at the backside.
Status LED ring
The color of the LED ring around the power button of the Base Unit give information on the status of the
system.
LEDs behavior Explanation
static red • receiving content from the Buttons and streaming towards the
display.
• pairing and software update of the Button is done. You can now
unplug the Button from the Base Unit.
• during the first phase of the Base Unit boot process.
blinking white • system is starting up (during the second phase)
• Button pairing is in progress
• software update of the Base Unit
breathing white • ECO standby mode
static white • awake and ready (i.e. showing the welcome message on the
display)
• pairing is done
red blinking • an error occurred
dark • deep standby/off
Power button
The button at the front of the Base Unit has a standby function once the Base unit is powered.
• When the system is in normal operational mode, a push makes the system goes into a pre-defined standby
mode.
• When the system is in standby, a push triggers the system to start up and it goes into normal operational
mode.
Back layout of the Base Unit
The connection panel is situated at the back of the Base unit.
CSE-200+ Specifications
