11R5914654 /04 G62 series
1.3 Main unit
Component locations
1
2
Image 1–7
1 Remote receiver (Front)
2 Projection lens
DC 12 V
HDB aseT
HDM I OUT
HDM I-2 IN
HDM I-1 IN
DVI -D
3G- SDI IN
ETH ERNET
USB
3D SY NC
IN
RS2 32
REM OTE
IN
OUT
3D SY NC
Z
INP UTEXI T
MEN U
LEN S
FOC US
OOM
ENT ER
3
6
7 6 8
9
6
4 5
Image 1–8
3 LED Status Indicator
4 Input/Output (I/O) Panel
5 Remote receiver (Top)
6 Adjustable feet
7 Control panel
8 Power socket (AC100-240V, 50-60Hz)
9 Power switch
