Page #32 background imageLoading...
Page #32 background image
R5914654 /04 G62 series32
3.1 Specifications of the UST lens
Overview
Throw ratio 0.361 (120”)
Focal length 9.49-9.55
F number 2.4
Zoom ratio No zoom
Throw distance 0.96-3.01m
Screen size 120” to 400”
Lens
configuration
3 group 23 elements
Brightness ratio 70% (for reference)
Net weight 2.715 kg
Lens specification table
Screen
diagonal
(inch)
W (cm) H (cm) P (cm)
3
A-P (cm) B (cm)
C=PD
(cm)
L (cm)
M (cm)=
(A-P)+(H/
2)
110 236,9 148,1 19,9 52,6 6,3 88,9 82,6 126,6
120 258,3 161,5 19,9 58,2 13,6 96,3 82,6 139,0
130 280,0 175,0 19,9 63,9 21,0 103,6 82,6 151,4
140 301,5 188,5 19,9 69,5 28,3 110,9 82,6 163,8
150 323,0 201,9 19,9 75,1 35,6 118,2 82,6 176,2
160 344,6 215,4 19,9 80,8 42,9 125,5 82,6 188,5
170 366,2 228,9 19,9 86,4 50,3 132,9 82,6 200,9
180 387,7 242,3 19,9 92,1 57,6 140,2 82,6 213,3
190 409,2 255,8 19,9 97,7 64,9 147,5 82,6 225,7
200 430,7 269,3 19,9 103,4 72,2 154,8 82,6 238,1
210 452,3 282,7 19,9 109,1 79,5 162,2 82,6 250,5
220 473,9 296,2 19,9 114,8 86,9 169,5 82,6 262,9
230 495,4 309,6 19,9 120,4 94,2 176,8 82,6 275,2
240 516,9 323,1 19,9 126,1 101,5 184,1 82,6 287,6
250 538,5 336,6 19,9 131,7 108,8 191,5 82,6 300,0
260 560,0 350,0 19,9 137,4 116,2 198,8 82,6 312,4
270 581,6 363,5 19,9 143,0 123,5 206,1 82,6 324,8
280 603,1 376,9 19,9 148,7 130,8 213,4 82,6 337,2
290 624,6 3690,4 19,9 154,4 138,1 220,8 82,6 349,6
300 646,2 404,0 19,9 160,0 145,5 228,1 82,6 361,9
310 667,7 417,3 19,9 165,7 152,8 235,4 82,6 374,3
320 689,3 430,8 19,9 171,3 160,1 242,7 82,6 386,7
UST lens R9801785(1)
3. feet turned completely in
