Barco G62 Series - Connecting to Video Sources

29R5914654 /04 G62 series
2.6 Connecting to video sources
Wiring diagram
DC 12 V
HDB as eT
HDM I OU T
HDM I- 2 IN
HDM I- 1 IN
DVI -D
3G- SD I IN
ETH ER NET
USB
3D SY NC
IN
RS2 32
REM OT E
IN
OUT
3D SY NC
Component video output
equipment
DVD PlayerVideo cassette recorder
1 2
1
2
Image 2–18
1 HDMI cable
2 HDMI cable
Notes on wiring diagram:
• The diagram shows the cables/connectors that may be used to connect to various devices.
• Due to the difference in applications for each country, the accessories required in some regions may be
different from those shown.
• This diagram is for illustrative purposes only, and does NOT indicate that these accessories are supplied
with the projector.
