R5914654 /04 G62 series54
Adjustment ranges (in turns) for the boresight screws for G62 + LSM type 2
Orientation A B C
Table top 3 3 3
Portrait (L) 5+ 1/4 5 + 1/4 2
Portrait (R) 5 2 5
Ceiling mount 7 + 1/2 2 3
Upright 5+ 1/2 3 3
The optical adjustments of the UST lens need to be done in the actual position of the projector.
UST lens R9801785(1)
