Barco MDSC-8231 User Manual

R5911692 /01 MDSC-823160
© 2020 Barco NV all rights reserved.
7.9 Technical specifications
Overview
Screen technology TFT AM LCD / IPS technology / LED backlight
LCD panel active screen size
(diagonal)
31.1” / 789 mm
LCD panel active screen size (H
x V)
698 x 368 mm
LCD panel aspect ratio (H:V) 17:9
LCD panel resolution 4k-2k (4096 x 2160)
Pixel pitch 0.1704 mm
Color support 1073 million (10-bit)
Color gamut Native: Wide color gamut (96% DCI-P3)
Calibrated color space: ITU 709 (default), BT. 2020, DCI-P3 D65
Viewing angle (H, V) 178° Hor / 178° Ver
Luminance Native: 550 cd/m² (Typical)
Default setting: 450 cd/ m² @6500K stabilized
Contrast ratio 1400:1 (typical)
LCD response time (Tr + Tf) 20 ms
White point Native: 7200K (Typical)
Calibrated: 5600K, 6500K, 7600K, 9300K
Gamma Native, 1.8, 2.2, 2.4, DICOM, Video
Housing color RAL 9003
Screen protection 2-side anti-reflective alkali-aluminosilicate glass
Keyboard Capacitive touch keyboard
Video input signals 4K-UHD input
• 1x DP 1.1 up to 4096 x 2160 @30Hz
• 2x DP 1.1 up to 2048 x 2160 @50Hz/60Hz
• 1x DP 1.2 MST up to 4096 x 2160 @50Hz/60Hz
• 2x HDMI 2.0 up to 4096 x 2160 @50Hz/60Hz
7
• 4K SDI:
4x 3G-SDI Quad link (each link up to 2048 x 1080 @50/60 Hz)
2x 12G-SDI up to 4096 x 2160 @50/60 Hz (SDI 1 or SDI 3)
FHD input (upscaled to 4K)
• 1x DVI
• 1x 3G-SDI (SDI 1 or SDI 3)
Video output signals SDI loopthrough (not available in Quad link):
• SDI 2: loopthrough of SDI 1
• SDI 4: loopthrough of SDI 3
1x DVI (4K display screen clone - downscaled to 1080i/1080p)
Video formats
• DisplayPort 1.2 MST (10 bit) up to 4096 x 2160@60Hz (displayed at
native resolution) with HDCP 1.3
• Dual stream DP 1.1 (10 bit) up to 2048 x 2160 x 2 @60Hz synchronized
(displayed at native resolution) with HDCP 1.3
• SDI compliance standards:
- 12G-SDI (10 bit): SMPTE ST-2082-10
- QUAD LINK 3G-SDI (10 bit): SMPTE ST 425-5 (Level A)
- 3G-SDI (10 bit) : SMPTE ST 424/425 (Level A)
- HD-SDI (10 bit): SMPTE ST 292
Important information
7: DP 1.2 SST to HDMI 2.0 adapter available from Barco

Barco MDSC-8231 Specifications

General

Panel type	IPS-Pro
Color gamut	96 %
Pixel pitch	0.1704 x 0.1704 mm
Screen shape	Flat
Response time	20 ms
Display diagonal	31.1 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Native aspect ratio	17:9
Maximum refresh rate	- Hz
Viewable size, vertical	368 mm
Contrast ratio (typical)	1400:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	698 mm
Display brightness (typical)	550 cd/m²
Supported graphics resolutions	4096 x 2160
DVI-D ports quantity	1
USB upstream port type	USB Type-B
Panel mounting interface	100 x 100, 200 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	47/63 Hz
Power consumption (off)	1 W
Power consumption (standby)	- W
Power consumption (typical)	18 W
Package weight	17000 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	ANSI/AAMI ES60601-1 (2005 + C1:09 + A2:10 + A1:2014 CAN/CSA-C22.2 No. 60601-1 (2014) IEC 60601-1:2005 + CORR. 1:2006 + CORR. 2:2007 + A1:2012 EN 60601-1: 2006 + CORR:2010 + A1:2013 + A12:2014 EMC: IEC 60601-1-2 (2014), EN 60601-1-2 (2015) EN55011 /CISPR 11, FCC CFR47 15 B (B) GB17625.1-2012; GB4943.1-2011; GB/T9254-2008 CE, c-UL-us, DEMKO, CCC, INMETRO, EAC IP20/IP45 ROHS-3, REACH, WEEE
Product color	White
Market positioning	Medical
Sustainability certificates	RoHS

Weight and Dimensions

Depth (without stand)	93 mm
Width (without stand)	777 mm
Height (without stand)	472 mm
Weight (without stand)	12100 g
