Barco MDSC-8231 User Manual

R5911692 /01 MDSC-8231 61
- SD-SDI (10 bit): SMPTE ST 259
• DVI (8 bit) up to 1920 x 1080 @60Hz with HDCP 1.3
• HDMI 2.0 up to 4096 x 2160 @60Hz RGB/YCbCr (4:2:0/4:2:2/4:4:4) with
HDCP 2.2 and 1.4
• HDMI 1.4 up to 4096 x 2160 @30Hz RGB/YCbCr (4:2:2/4:4:4) with
HDCP 1.4
Remote control Use Type B port for FW download & DDC protocol on DVI and DP auxiliary
channel (on DP main connector)
Power consumption (Max) 190W / 24V ± 10%
External power supply AC input: 100 – 250 VAC / 47-63 Hz auto-switch
DC output: +24 VDC / 10 A
Max power out: 250 W
DC power output DVI connector: +5V on pin 14 & 16 / 500mA
DP connector: +3.3V / 500mA
DC out connector: +5V / 2A
Power management Low power mode: 33W (typical)
Power-off: ~ 1 W
Dimensions display (W x H x D) 777 x 472 x 93 mm (30.6 x 18.6 x 3.7 in)
Net weight display 12.1 kg (26.6 lbs)
Net weight packaged 17.0 kg (37.5 lbs)
Mounting standard VESA (100 x 100 mm, 200 x 100 mm)
Certifications
• ANSI/AAMI ES60601-1 (2005 + C1:09 + A2:10 + A1:2014) (Medical
Electrical Equipment - Part 1: General Requirements for Basic Safety
and Essential Performance) (includes Deviations for United States)
• CAN/CSA-C22.2 No. 60601-1 (2014) (Medical Electrical Equipment -
Part 1: General Requirements for Basic Safety and Essential
Performance) (includes National Differences for Canada)
• IEC 60601-1:2005 (Third Edition) + CORR. 1:2006 + CORR. 2:2007 +
A1:2012: General requirements for basic safety and essential
performance)
• EN 60601-1: 2006 + CORR:2010 + A1:2013 + A12:2014 (Medical
electrical equipment Part 1: General requirements for basic safety and
essential performance)
• Electromagnetic Compatibility: EMC Medical EMC Standards: IEC
60601-1-2 (2014), EN 60601-1-2 (2015) EN55011 /CISPR 11, FCC
CFR47 Part 15 Subpart B (Class B)
• GB17625.1-2012; GB4943.1-2011; GB/T9254-2008
• Approvals/Marking: CE (Medical Device Class I), c-UL-us, DEMKO,
CCC
• RoHS-3, REACH, WEEE
Operating temperature 0 ÷ 35 °C (for performance); 0 ÷ 40 °C (for safety)
Storage temperature -20 ÷ +60°C
Operating humidity 10 ÷ 90% (non-condensing)
Storage humidity 5 ÷ 90% (non-condensing)
Protection level IP20 (IP45 front side only)
Warranty 3 years
Timings full-HD & 4MP
Format SDI DVI HDMI DP 1.1
720x480p@59.94Hz N Y Y Y
720x480p@60.00Hz N Y Y Y
720x576p@50.00Hz N Y Y Y
800x600p@56.25Hz N Y N Y
Important information

Barco MDSC-8231 Specifications

General

Panel type	IPS-Pro
Color gamut	96 %
Pixel pitch	0.1704 x 0.1704 mm
Screen shape	Flat
Response time	20 ms
Display diagonal	31.1 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Native aspect ratio	17:9
Maximum refresh rate	- Hz
Viewable size, vertical	368 mm
Contrast ratio (typical)	1400:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	698 mm
Display brightness (typical)	550 cd/m²
Supported graphics resolutions	4096 x 2160
DVI-D ports quantity	1
USB upstream port type	USB Type-B
Panel mounting interface	100 x 100, 200 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	47/63 Hz
Power consumption (off)	1 W
Power consumption (standby)	- W
Power consumption (typical)	18 W
Package weight	17000 g
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	ANSI/AAMI ES60601-1 (2005 + C1:09 + A2:10 + A1:2014 CAN/CSA-C22.2 No. 60601-1 (2014) IEC 60601-1:2005 + CORR. 1:2006 + CORR. 2:2007 + A1:2012 EN 60601-1: 2006 + CORR:2010 + A1:2013 + A12:2014 EMC: IEC 60601-1-2 (2014), EN 60601-1-2 (2015) EN55011 /CISPR 11, FCC CFR47 15 B (B) GB17625.1-2012; GB4943.1-2011; GB/T9254-2008 CE, c-UL-us, DEMKO, CCC, INMETRO, EAC IP20/IP45 ROHS-3, REACH, WEEE
Product color	White
Market positioning	Medical
Sustainability certificates	RoHS

Weight and Dimensions

Depth (without stand)	93 mm
Width (without stand)	777 mm
Height (without stand)	472 mm
Weight (without stand)	12100 g
