2. Installation requirements
2.1 Mechanical requirements for the X 8 rental display
Weight
Do not underestimate the weight of a complete X8 rental display. Be sure that the floor or truss installation on which the X8 rental
display has to be installed is capable of handling five (5) times the complete load of the display. Note that one X8 rental tile weighs
approximately 40 kg (or 41 kg per square meter display). Do not forget to take into account the weight of the ballast required in case
of a base stand X8 rental display.
Levelled surface
The surface on which the X8 rental display has to be installed must be levelled. Never install the X8 rental display on an inclined
surface.
Do not install a base stand X8 display upon a smooth surfaces. Place rubber mats between the foot beams of the LED wall and the
smooth surface to increase friction.
WARNING: En su re that, w h en i nstalling a base stand X8 rental d isplay upon a platform, the top of the LED -wall
does not reach more then 20 meters a bove ground level.
Ballast
Depending on the expected wind load, the height of the display and the position of the LED-wall upon the foot beams (somewhere
between front and middle) additional weight (ballast) will be required. Use the “Ballast calculator” tool available on Barco’s secured
web site to calculate the minimum ballast you require for safe installation of your X8 rental display.
12
R5905160 X8 RENTAL DISPLAY 25/02/2013
