A. Dimensions
A.4 Dimensions of the X8 Single Truss Beam
Dimensions X8 Single Truss Beam
1136
120120
Image A-4
Dimensions given in millimeters.
R5905160 X8 RENTAL DISPLAY 25/02/2013 73
