BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - INSTALLATION
The e-ink display of the PRC-4090 Battery Pack displays ve dots indicating
battery charge levels:
Zero dots <5%
Solid 1 black dots 5%-20%
Solid 2 black dots 20%-40%
Solid 3 black dots 40%-60%
Solid 4 black dots 60%-80%
Solid 5 black dots 80%-100%
When charging the PRC-4090 Battery Pack, the LED indication will animate.
Regular charging (24V charger): a blinking dot indicates the capacity of the
battery i.e if the battery is at 25% charge, the second dot will blink while the
rst will remain solid.
Fast Charging (48V charger): the dots will animate sequentially from the
appropriate charge level of the battery i.e if the battery is at 25% charge, the
rst two dots will remain solid while the last three dots will animate sequen-
tially.
The Control Handset display will also indicate the speed of the charge with the
following icons:
Regular charge (24V charger)
Fast charge (48V charger)
