BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - INSTALLATION

PRC-4090 System Docking Station – Rear

Earth stud

Coaxial connector

ATU connector

PRC-4090 Handset connector

Ethernet

DC Power In
