BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - ADVANCED OPERATION
Network
This menu can be accessed from the
Settings menu.
Settings Network
The PRC-4090 HF SDR Transceiver has the ability to interface with IP networks,
allowing mobile cellular handsets, tablets and desktop PCs to connect directly
to the transceiver via Ethernet or WiFi with the use of specialised adapters. For
more information, see the Barrett IP Connectivity and Networking Guide (P/N
BCMPRC-40907).
IMPORTANT: Ensure that the USB Interface Unit is attached BEFORE the USB
device is inserted.
When using a 4050/4090 Control Handset without a docking station, a PRC-
4090 Handset USB Interface (4090-01-27) must be attached to the rear of the
handset.
The PRC-4090 Handset USB Interface is attached as shown in the diagrams
below. Once in place, turn the wheel until unit is secure.
