114
BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - INSTALLATION
Battery Pack
The Barrett PRC-4090 Transceiver can be powered in multiple ways. For man-
pack use, it has been designed to use the Barrett PRC-4090 16Ah Battery pack
or external military battery. The PRC-4090 Battery Pack has an in-built charger/
battery management system. This battery pack can be charged in multiple ways
as outlined over the following pages.
With the battery pack tted, the transceiver can be operated and the battery
pack charged simultaneously when a DC input of between 10 V DC and 70 V
DC is supplied to the unit.
Additionally, the PRC-4090 battery pack can be charged connected or discon-
nected to the manpack using the AC/DC input universal power adaptor unit or
directly from a 12 or 24 V tactical solar panel (MPPT charger tted for optimised
current input), or BB series military battery congured as shown in the follow-
ing diagrams.
