134
BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - INSTALLATION
Handset Docking Station Congurations
The Handset Docking Station can be congured for either portrait or landscape
use of the Control Handset. The exploded diagrams below show each of these
congurations.
Portrait Conguration
Landscape Conguration
