91
BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - ADVANCED OPERATION
The diagram below shows the possible connections between the above PRC-
4090 Control Handset and an IP network.
1
PRC-4090 Control Handset (P/N 4090-01-09)
2
PRC-4090 Handset USB Interface (4090-01-27)
3
WiFi Adaptor (P/N BCO40508)
4
USB to Ethernet Adaptor with USB ports (P/N BCA40505)
5
Ethernet (RJ45) cable
