BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - ADVANCED OPERATION

The below diagram shows the network connection from a Barrett PRC-4090 HF

SDR Transceiver in Mobile congura tion (P/N 4091-00-10).

Barrett PRC-4090 HF SDR Transceiver in Mobile congura-

tion (P/N 4091-00-10)

Ethernet (RJ45) cable
