BARRETT PRC-4090 TACTICAL HF SDR TRANSCEIVER - INSTALLATION
Connection Details for a PRC-4090 Transceiver with Mobile Pack
and a 2018 Mobile Magnetic Loop Antenna
1
Barrett PRC-4090 HF SDR Transceiver (P/N 4090-00-01)
2
Barrett PRC-4090 System Docking Station (P/N 4090-05-00)
3
Anti-Vibration Mounting Plate (P/N 4090-05-07)
4
PRC-4090 Control Handset (P/N 4090-01-09) and Control Handset
Docking Station (P/N 4090-05-03)
5
2018 Mobile Magnetic Loop Antenna (P/N BC201801)
6
Control & Coaxial Cable 6m (P/N BCA201904)
7
Ground (earth)
8
IP Network Connection via RJ45 cable
9
Interface cable 6 m - integral coaxial/control with connectors to suit
4090 SDS (P/N 2019-00-02)
10
Circuit Breaker
11
12 V (or 24 V) DC battery
