2-1
Installation Verification Operator Manual 920512-768
2.1 General Equipment drawing (920-512-757) showing all utility and space
requirements was sent after the order for the Basil
®
5700LSR Cage
and Rack Washer was received. The clearance space specified on
equipment drawing is necessary for proper installation, operation
and maintenance. Uncrating/Installation Instructions (P920512-767)
were provided with the washer. If these documents are missing or
misplaced, contact STERIS giving the serial, equipment and model
numbers of the unit. Replacement copies will be sent to you
promptly.
2.2 Technical
Specifications
These specifications are intended to describe the technical informa-
tion given on the identification nameplate of the washer and to state
other relevant information. Refer to equipment drawing or identifica-
tion nameplate located on frame of mechanical core, below main
electrical box, for proper voltage and amperage.
2.2.1 Voltage, Amperage and
Power Consumption
This unit operates either on:
• 208 V~, three-phase, 60 Hz;
• 380/400/415 V~, three-phase, 50 Hz;
• 480 V~, three-phase, 60 Hz.
A protective ground conductor is required (Class 1 Equipment).
Installation Category II (Overvoltage Category).
Refer to S
ECTION 3.9, ELECTRICAL CONNECTIONS, of Uncrating/Instal-
lation Instructions (P920512-767) for proper connection.
Maximum currents and power consumptions:
Amp kVA
208 V 37.0 13.3
380/400/415 V 18 15
480 V 18 15
IMPORTANT: A listing of the Safety Precautions to be observed when operating this Cage and Rack
Washer can be found in S
ECTION 1. Do not operate equipment until you have become familiar with this
information.
INSTALLATION VERIFICATION
2
