Basil 5700LSR - Vertical Self-Cleaning Filter

6-12
920512-768 Operator Manual Routine Maintenance
Figure 6-4. Vertical Self-Cleaning Filter
Tank 1
DETAIL A
DETAIL B
Push Tank 1 Recirculation Valve to the Right
Self-Cleaning Filter
Cartridge
Return Outlet
Piping
