6-16
920512-768 Operator Manual Routine Maintenance
6.6 Change Printer
Paper
See Figure 6-6.
NOTE: Do not operate printer without paper.
1. Press on the dots on printer cover to release latch; pull cover
out towards you to completely disengage cover; then, gently
swing it down 180° until it rests against equipment panel (see
Figure 6-6).
2. Press on the indentation on the right side-wall of paper cover,
gently pull to release and swing door to the left until it is open
(see Figure 6-7).
3. Cut leading edge of paper roll straight and square with the sides
as shown on Figure 6-8.
4. Mount paper roll on paper-roll-holder, two plastic protrusions
shaped like domes, inside paper compartment. Paper must curl
up as shown (see Figure 6-9). Paper roll core must properly align
with paper-roll-holder. Make sure paper-roll-holder fits inside
paper core and paper roll can turn freely.
5. Hold both edges of paper and insert it straight into paper slot of
printer mechanism. Printer feeds paper automatically.
6. Press FEED Button to get desired length of paper fed through
mechanism. Do not pull paper in either direction through printer
mechanism.
7. Remove take-up spool and insert leading edge of paper into slit
on its shaft. Wrap paper around spool two or three times tightly
and install take-up spool in printer. First make sure that gear on
take-up spool aligns with gear on printer and then press the
other end of shaft so it snaps in on metal frame.
8. Close paper cover and then close front cover.
NOTE: When changing paper roll, take note of the following:
1) Use a paper that meets the printer specifications.
2) Do not use a paper that is glued to the core.
3) Do not fold leading edge of paper when you use a new roll.
4) Do not operate the printer without paper or ribbon; this leads to
rapid deterioration of the print head.
5) Do not use any sharp object to remove paper jams.
6) Do not pull on the paper while the printer is printing.
IMPORTANT: Printer will not operate if there is no paper in paper
compartment.
WARNING – PERSONAL
INJURY AND/OR EQUIP-
MENT DAMAGE HAZARD:
Regularly scheduled preven-
tive maintenance, in addition
to faithful performance of
minor maintenance described
in this manual, is required for
safe and reliable operation of
this equipment. Contact
STERIS to schedule preven-
tive maintenance.
WARNING – ELECTRIC SHOCK
HAZARD:
Always set building
electrical-supply disconnect
switch and console master
power switch to OFF before
performing any preventive
maintenance functions within
the compartments. Electrical
shock can cause serious
injury.
