3-2
920512-768 Operator Manual Component Identification
3.2 Operator Terminal See Figure 3-2.
The Basil 5700LSR Cage and Rack Washer is equipped with an
Allen-Bradley CompactLogix
™ PLC control system
1
that features
twelve cycles for processing a wide variety of loads.
System monitors and controls washer operations and functions and
also monitors current status of chamber, including current chamber
temperature and time remaining in phase.
Control system offers three operation modes: Supervisor, Service
and Cycle. The first two modes are password protected. Cycle mode
is always available.
In case of battery failure, an alarm warns operator that battery (P117-
915-348) must be replaced.
There is an operator terminal on load side and an operator terminal
on unload side for double door units. Identical information is dis-
played on both load and unload operator terminals.
3.2.1 Login Passwords Supervisors and service users with appropriate passwords can
access Supervisor mode.
Only a qualified service technician can access Service mode. A pre-
defined password is required to access Service mode.
3.2.2 Cycle Mode Cycle mode is the default operating mode of the washer. No pass-
word is required to enter in Cycle mode.
Operator closes door, manually selects desired cycle in touch
screen, presses START touch pad and appropriate cycle starts.
3.2.3 Supervisor Mode Supervisor mode allows supervisor to modify preprogrammed param-
eters and options within a range of factory set values such as date
and time and to enable printer functions.
Supervisor mode access is secured by a password. Supervisor
password is configured in Supervisor mode.
Pa ssw ord s
Opera tors
Cycle s
1
CompactLogix™ is a trademark of Allen-Bradley, a Rockwell Automation Company.
