Basil 5700LSR - Central Spray Header Manifold (Accessory)

6-9
Routine Maintenance Operator Manual 920512-768
Figure 6-2. Central Spray Header Manifold (Accessory)
Remove End Spray
Jets
Remove End Spray Jets
Figure 6-3. Bottle Washing Cart (Accessory)
DETAIL
Vee Spray Jet Nozzle
5/46" Hole
Lock Nut
Spray
Arm
Groove
Spray Header
Hub
Spray Arm
