Basler A202k User Manual

Configuring the Camera
BASLER A202k 4-17
DRAFT
4.2.4.12 Right Side Gain
4.2.4.13 Right Side Offset
Purpose: To set the gain for the right side of the CCD array or to read the current right side gain
setting. See Section 3.5 for more information on gain.
Type: This is a read or write command.
Read Command: Cmd-ID R/W-Flag Data Length Data
0x82 1 2 -
Response: Cmd-ID R/W-Flag Data Length Data
0x82 0 2 2 Bytes
Write Command: Cmd-ID R/W-Flag Data Length Data
0x82 0 2 2 Bytes
Response: None
Data Format: Byte 1 Low byte of right side gain setting
Byte 2 High byte of right side gain setting
Data Range: Right side gain settings can range from 288 to 1023 (0x0120 to 0x03FF).
Purpose: To set the offset for the right side of the CCD array or to read the current right side offset
setting. See Section 3.5 for more information on offset.
Type: This is a read or write command.
Read Command: Cmd-ID R/W-Flag Data Length Data
0x83 1 2 -
Response: Cmd-ID R/W-Flag Data Length Data
0x83 0 2 2 Bytes
Write Command: Cmd-ID R/W-Flag Data Length Data
0x83 0 2 2 Bytes
Response: None
Data Format: Byte 1 Low byte of right side offset setting
Byte 2 High byte of right side offset setting
Data Range: Right side offset settings can range from 0 to 255 (0x0000 to 0x00FF).
