Basler A202k User Manual

Configuring the Camera
BASLER A202k 4-15
DRAFT
4.2.4.8 Area of Interest Starting Line
4.2.4.9 Area of Interest Height in Lines
Purpose: To set the starting line for the area of interest or to read the current setting. See Section 3.7
for details on the area of interest.
Type: This is a read or write command.
Read Command: Cmd-ID R/W-Flag Data Length Data
0xA8 1 2 -
Response: Cmd-ID R/W-Flag Data Length Data
0xA8 0 2 2 Bytes
Write Command: Cmd-ID R/W-Flag Data Length Data
0xA8 0 2 2 Bytes
Response: None
Data Format: Byte 1 Low byte of the starting line setting
Byte 2 High byte of the starting line setting
Data Range: The starting line setting can range from 0x0000 to 0x03EB.
When you set line n using this command, the actual starting line will be
n + 1. For example, if you set the starting line to 0 with this command, the
actual starting line = 0 + 1 = 1.
Purpose: To set the height in lines for the area of interest or to read the current setting. See Section
3.7 for details on the area of interest.
Type: This is a read or write command.
Read Command: Cmd-ID R/W-Flag Data Length Data
0xAA 1 2 -
Response: Cmd-ID R/W-Flag Data Length Data
0xAA 0 2 2 Bytes
Write Command: Cmd-ID R/W-Flag Data Length Data
0xAA 0 2 2 Bytes
Response: None
Data Format: Byte 1 Low byte of the height in lines setting
Byte 2 High byte of the height in lines setting
Data Range: The height in lines setting can range from 0x0001 to 0x03EC

See Section 3.7.1 or a list of guidelines which must be followed when entering the
settings for the area of interest.
