Basler A202k User Manual

Configuring the Camera
BASLER A202k 4-19
DRAFT
4.2.4.16 Test Image Command
Purpose: To enable or disable a test image. See Section 3.10 for an explanation of the available test
images.
Type: This is a read or write command.
Read Command: Cmd-ID R/W-Flag Data Length Data
0xA1 1 1 -
Response: Cmd-ID R/W-Flag Data Length Data
0xA1 0 1 1 Bytes
Write Command: Cmd-ID R/W-Flag Data Length Data
0xA1 0 1 1 Byte
Response: None
Data Format: Byte 1 An ID that specifies the test image
(see the table below).
ID Test Image
0x00 No test image
0x01 Test Image 1 (diagonal gradient pattern)
0x02 Test Image 2 (moving gradient pattern)
0x03 Test Image 3 (vert./horiz. gradient pattern)
