Basler A202k User Manual

Camera Interface
2-8 BASLER A202k
DRAFT
2.5.4 Video Data
2.5.4.1 Bit Assignments
Table 2-3 lists the assignment of pixel data bits to the input ports on the transmitter in the camera
and the corresponding output pins on the receiver in the frame grabber. These bit assignments
comply with the Camera Link standard. As shown in the table, the bit assignments for pixel data
vary depending on the output mode setting of the camera. The available output modes are
explained in more detail in Section 2.5.4.2.
Table 2-3 also shows the assignment for the frame valid bit, the line valid bit and the pixel clock.
These assignments are constant for all output modes.
Port Camera
Frame
Grabber
Dual 10 Bit
Output Mode
Dual 8 Bit
Output Mode
Port A0 TxIN0 RxOUT0 Odd Pixel Bit 0 Odd Pixel Bit 0
Port A1 TxIN1
RxOUT1 Odd Pixel Bit 1 Odd Pixel Bit 1
Port A2 TxIN2
RxOUT2 Odd Pixel Bit 2 Odd Pixel Bit 2
Port A3 TxIN3
RxOUT3 Odd Pixel Bit 3 Odd Pixel Bit 3
Port A4 TxIN4
RxOUT4 Odd Pixel Bit 4 Odd Pixel Bit 4
Port A5 TxIN6
RxOUT6 Odd Pixel Bit 5 Odd Pixel Bit 5
Port A6 TxIN27
RxOUT27 Odd Pixel Bit 6 Odd Pixel Bit 6
Port A7 TxIN5
RxOUT5 Odd Pixel Bit 7 Odd Pixel Bit 7 (MSB)
Port B0 TxIN7
RxOUT7 Odd Pixel Bit 8 Even Pixel Bit 0
Port B1 TxIN8
RxOUT8 Odd Pixel Bit 9 (MSB) Even Pixel Bit 1
Port B2 TxIN9
RxOUT9 Not Used Even Pixel Bit 2
Port B3 TxIN12
RxOUT12 Not Used Even Pixel Bit 3
Port B4 TxIN13
RxOUT13 Even Pixel Bit 8 Even Pixel Bit 4
Port B5 TxIN14
RxOUT14 Even Pixel Bit 9 (MSB) Even Pixel Bit 5
Port B6 TxIN10
RxOUT10 Not Used Even Pixel Bit 6
Port B7 TxIN11
RxOUT11 Not Used Even Pixel Bit 7 (MSB)
Port C0 TxIN15
RxOUT15 Even Pixel Bit 0 Not Used
Port C1 TxIN18
RxOUT18 Even Pixel Bit 1 Not Used
Port C2 TxIN19
RxOUT19 Even Pixel Bit 2 Not Used
Port C3 TxIN20
RxOUT20 Even Pixel Bit 3 Not Used
Port C4 TxIN21
RxOUT21 Even Pixel Bit 4 Not Used
Port C5 TxIN22
RxOUT22 Even Pixel Bit 5 Not Used
Port C6 TxIN16
RxOUT16 Even Pixel Bit 6 Not Used
Port C7 TxIN17
RxOUT17 Even Pixel Bit 7 Not Used
LVAL TxIN24
RxOUT24 Line Valid Line Valid
FVAL TxIN25
RxOUT25 Frame Valid Frame Valid
Not Used TxIN26
RxOUT26 Not Used Not Used
Not Used TxIN23
RxOUT23 Not Used Not Used
PClk TxCLKIn
RxCLKOut Pixel Clock Pixel Clock
Table 2-3: Bit Assignments
