1.2 Performance Specifications
Category Specification
Sensor Interline Transfer Progressive Scan CCD Sensor
Pixels 1004 (H) x 1004 (V)
Pixel Size 7.4 µm x 7.4 µm
Spectral Response See Figure 1-1
Photo Response Non-uniformity ± 5% (typical)
Dark Signal Non-uniformity ± 1 gray value (typical)
Pixel Clock Speed 40 MHz
(20 MHz when horizontal or full binning is used)
Max. Frame Rate 48 Frames/sec. at full resolution
Video Output Type Camera Link LVDS
(RS-644 when used with the optional Basler Interface Controller)
Video Output Formats
Dual 8 Bit or Dual 10 Bit
Synchronization Via external ExSync signal or free-run
Exposure Time Control Level-controlled, programmable, or free-run
Gain and Offset Programmable via an RS-644 serial connection on the frame
grabber
Power Requirements
12 VDC (± 10%), max. 5.5 W, < 1% ripple
Lens Adapters C-mount or F-mount
Housing Size (L x W x H) without lens adapter: 37.6 mm x 62 mm x 62 mm
with C-mount adapter: 40.1 mm x 62 mm x 62 mm
with F-mount adapter: 69.1 mm x 62 mm x 62 mm
Weight
without lens adapter: ~ 180 g.
with C-mount adapter: ~ 220 g.
with F-mount adapter: ~ 290 g.
Conformity
CE, FCC
Table 1-1: A202k Performance Specifications
