4.2.5.9 Read Reference Gain Values
Purpose: To read the reference gain values that are determined during the camera’s factory
calibration procedure (see Section 3.5.2 for information on how to use these values).
Type: This is a read only command.
Read Command: Cmd-ID R/W-Flag Data Length Data
0x08 1 16 -
Response: Cmd-ID R/W-Flag Data Length Data
0x08 0 16 16 Bytes
Data Format: Each reference value is stored as 16 bits followed by a decimal point followed
by 16 more bits.
Byte 1 Low byte after the decimal point for the left side
reference gain value
Byte 2 High byte after the decimal point for the left side
reference gain value
Byte 3 Low byte before the decimal point for the left side
reference gain value
Byte 4 High byte before the decimal point for the left side
reference gain value
Byte 5 Low byte after the decimal point for the right side
reference gain value
Byte 6 High byte after the decimal point for the right side
reference gain value
Byte 7 Low byte before the decimal point for the right side
reference gain value
Byte 8 High byte before the decimal point for the right side
reference gain value
Bytes 9 to 16 Reserved. Should be ignored.
