Configuring the Camera
BASLER A202k 4-3
DRAFT
Using the Refresh and Apply Buttons
Two buttons always appear at the bottom of the configuration tool window, the Refresh button and
the Apply button.
Typically, if you make a change to one or more of
the settings on a tab, you must click the Apply
button for that change to be transmitted from the
configuration tool to the camera’s Work Set. Be-
cause the parameters in the Work Set control the
current operation of the camera, when you click the Apply button, you will see an immediate
change in the camera’s operation.
The Refresh button can be used at any time to make sure that the configuration tool is displaying
the current settings for the parameters in the Work Set. When you click the Refresh button, the
configuration tool queries the camera to determine the current setting for each parameter in the
Work Set and updates the display on each tab.
4.1.4 Configuration Tool Help
The Camera Configuration Tool includes a complete on-line help file which explains how to use
each tab and how the settings on each tab will effect the camera’s operation. To access on-line
help, press the F1 key whenever the configuration tool is active.
Keep in mind that the Work Set is stored in a volatile memory. Any changes you make
to the Work Set using the configuration tool will be lost when the camera is switched
off. To save changes you make to the Work Set, go to the Sets Tab and save the mod-
ified Work Set into one of the camera’s 15 User Sets. The User Sets are stored in non-
volatile memory and will not be lost when the camera is switched off (see Section 3.11).
If you want your changes to be loaded into the Work Set at the next power on, go to
the Sets Tab and set the Startup Pointer to the User Set where you saved your
changes.
