Basler GigE VISION CAMERAS User Manual

Pixel Data Formats AW00118303000
160 Basler racer GigE
When the camera is set for YUV 4:2:2 (YUYV) output, the pixel data output for the Y component is
8 bit data of the “unsigned char” type. The range of data values for the Y component and the
corresponding indicated signal levels are shown below.
The pixel data output for the U component or the V component is 8 bit data of the “straight binary”
type and will always be zero.
B
m-7
Y P
n-3
7 ... 0
B
m-6
U P
n-3
7 ... 0
B
m-5
Y P
n-2
7 ... 0
B
m-4
V P
n-3
7 ... 0
B
m-3
Y P
n-1
7 ... 0
B
m-2
U P
n-1
7 ... 0
B
m-1
Y P
n
7 ... 0
B
m
V P
n-1
7 ... 0
This Data Value
(Hexadecimal)
Indicates This Signal Level
(Decimal)
0xFF 255
0xFE 254
 
 
 
0x01 1
0x00 0
This Data Value
(Hexadecimal)
Indicates This Signal Level
(Decimal)
0x00 0
