AW00118303000 Physical Interface
Basler racer GigE 59
Using the Inputs with RS-644 LVDS
The inputs on the camera can accept RS-644 low voltage differential signals (LVDS).
If you are supplying an RS-644 LVDS signal to an input on the camera, the 120 ohm termination
resistor on that input must be enabled. The input will not reliably react to RS-644 signals if the
resistor is disabled.
For the camera’s I/O circuitry to operate properly, you must supply a ground as shown in Fig. 17.
Although the RS-644 standard allows several devices to be connected together in
a "multidrop" configuration, we strongly recommend that you do not include any
camera input in an RS-644 multidrop. Instead, we strongly recommend that you
use a direct, point-to-point connection between your RS-644 transmitter and the
camera input.
