Battenfeld PLUS 250/50 - Page 28

Technical Data
A: PL120100.030
B: PL120000.030
E: 03.93 / T. Weiß
G: 06.93 / T. Weiß
Chapter: 3
Page: 4
Injection component 75
Srew D = 18 mm (0,709 inch)
3038 bar (44050 psi)
Screw D = 22 mm (0,866 inch)
2034 bar (29500 psi)
Screw D = 25 mm (0,984 inch)
1575 bar (22840 psi)
Screw D = 30 mm (1,181 inch)
1094 bar (15860 psi)
1
2
4
3
100
90
80
70
60
50
40
30
20
10
400200 1200 1400 200018001600 2200 2400 3000280026001000800600
bar
2900 5800 8700 11600 14500 17400 2320020300 26100 29000 31900 34800 37700 4350040600 psi
4 3 2
1
Bild: PL-0016.WMF
p [%]
