A: PL120100.057
B: PL120100.057
E: 03.93 / T. Weiß
G: 06.93 / T. Weiß
Chapter: 5.7
Page: 1
?
Structure and Function
Operating unit
(CTD)
Control unit
(STU, ALS)
STU
500
AIO
172
KOP
500
CC
11
CA
16
CA
16
CE
32
DNT
24
STU-BUS
ALS-BUS
Bild: PL-0028.DRW
5.7 Control
5.7.1 Description of electronic system
1) General
The real-time control system UNILOG 1020 is the centre of all
control tasks required to run the machine properly.
The control system consists of two system units:
a) operating unit for the display and presetting of all process-
relevant data.
b) control unit for process control and regulation.
The control rack has a modular structure and was conceived
for the Europe card format. All modules are housed in a
protected plug-in case.
2) Structure
